SR:ONE ULTERGA

Name: SR:ONE ULTERGA
Brand: Quick Pro
Price: 4449.0 USD
Availability: InStock

$4,449.00

COMPLETE BIKE Color: Raw Carbon

Raw Carbon

size: 480

480

500

520

540

560

580

600

Quantity

SR:ONE ULTERGA

SR:ONE - Ultra Light/Climbing

Achieving the perfect balance of lightness and strength requires mastery of materials, design, and testing. Each carbon ply is precisely oriented, resin systems are carefully tuned, and every tube profile is validated through rigorous analysis and iteration. Performance standards are continuously refined to push beyond convention. The result: a frameset that weighs just 639g—proof that strength and minimal weight can coexist.

Key Features

−

Light and Strong

Built around one-piece molding technology, the frame strikes the perfect balance between lightweight design, rigidity, and strength.

Advanced Materials

Built with premium Toray T1100 and M56 high-grade carbon fibers, the frame has exceptional stiffness and responsiveness.

Ultra-Light Integrated Handlebar

Engineered for exceptional stiffness and precision handling — giving you total control in every corner.

Key Specifications

−

Model

SR:ONE

Material

T1100 & M56

Headset

52 x 52 mm

BB

BB86

Thru-axle

F/ 100×12mm R/ 142×12mm

Tire (Max.)

700×32c

Brakes

Flat-mount

Weight

Frame/639g±5% Fork/329g±5%

Wheels

CANWIN RC50 or F50C

Inner Tube

700 x 28c

Saddle

SAMASSI 3D Print Saddle

Handlebar

CANWIN ZEPHYR ZZL

Size & Fit

−

Label	Specification	480	500	520	540	560	580	600
A	Size / ST Length (mm)	480	500	520	540	560	580	600
B	Virtual TT (mm)	510.1	522	534	547	559.6	575	591
C	ST Angle (°)	74.7°	74.4°	74.1°	73.8°	73.5°	73.2°	72.9°
D	HT Angle (°)	71.5°	72°	72.6°	72.9°	73.1°	73.3°	73.3°
E	HT Length (mm)	110	115	125	140	155	175	195
F	RC Length (mm)	410	410	410	410	410	410	410
G	Wheel Base (mm)	971.4	976.4	978.7	986.3	994.1	1004.3	1016.9
H	Fork Rake (mm)	48	48	45	45	45	45	45
I	BB Drop (mm)	72	72	69	69	69	69	69
J	Fork Length (mm)	368	368	368	368	368	368	368
K	Standover (mm)	714.6	725.1	749.6	768.9	785.1	799.3	819.5
	Reach (mm)	370.3	377.6	383.9	388.9	394.6	400.9	407.6
	Stack (mm)	510.9	517.5	526.8	542.2	557.3	576.7	596.2
